Full Color Outdoor Digital Signage P6 3D HD Led Display Screen
960*960mm Iron Cabinet
Quick detail of Outdoor Digital Signage:
1, Pixel Pitch: 4mm. 5mm, 6.67mm
2, SMD LEDs, Wide viewing angle: 160°/ 140°.
3, Digital Process: 16bits.
4, Standard cabinet size: Customized, cabinet weight: 40kg/Sqm.
5, Grey Level: 16 Bit
6, Recommended minimum viewing distance: 5-7m.
7, Material: Die Casting Aluminum
Description of Outdoor Digital Signage:
Outdoor Digital Signage pixel include 4mm, 5mm, 6.67mm, 8mm, 10mm,
16mm, within these pixels, 4mm, 5mm, 6.67mm are the most
hot-selling and highest cost-effective series. You can use it on
car for advertising or fixed in some place as billboard or on
building.
Specification of Full Color LED Screen:
| LM-P4 | LM-P5 | LM-P6 |
| Physical Pitch | 4mm | 5mm | 6.67mm |
| Pixel Configuration | SMD1415 | SMD1415 | SMD2727 |
| Pixel Density | 62,500 pixels/Sqm | 40,000 pixels/Sqm | 22,376 pixels/Sqm |
| Module Dimensions(W x H) (mm) | 320 x 160 | 320 x 160 | 320 x 160 |
| Panel Dimensions (mm) | 960 x 960 x 150 | 960 x 960 x 150 | 960 x 960 x 150 |
| NO. of Modules Per Panel (W x H) | 3 x 6 | 3 x 6 | 3 x 6 |
| Physical Resolution of Module (W x H) | 80 x 40 | 64 x 32 | 48 x 24 |
| Physical Resolution of Panel (W x H) | 240 x 240 | 192 x 192 | 144 x 144 |
| Panel Material | Steal / Aluminum | Steal / Aluminum | Steal / Aluminum |
| Weight (kg/Sqm) | 65 / 45 | 65 / 45 | 45 |
| | | |
| Processing | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 2,000 : 1 | 2,000 : 1 | 2,000 : 1 |
| Average Power Consumption | 360 W /Sqm | 360 W /panel | 360 W /panel |
| Max Power Consumption | 900 W /Sqm | 900 W /panel | 900 W /panel |
| Brightness | >6,500 nits | >6,500 nits | >6,500 nits |
| Refresh Rate | >1,920 Hz | >1,920 Hz | >1,920 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Rear | Rear | Rear |
| IP Rating (Front/Rear) | IP 65 | IP 65 | IP 65 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/8 Scan | 1/8 Scan | 1/8 Scan |
Product Image:
Feature Of Full Color LED Screen:
High IP Rating IP65, good waterproof and dust resistance, suitable
for every condition.
Wide viewing angle 160° for broader reach, seamless in all
direction with same image quality output, suitable for large
gatherings.
High brightness from 6,000nits to 9,000nits, visible from every
direction even face to direct sunshine.
Good heat dissipation with fans and using meanwell power supply,
long lifespan.
You can adjust the resolution by change modules directly, this can
save your cost and labor.
250x250mm module, compatible with various pitches such as
PH2.6/PH2.9/PH3.9, high selectivity
High-precision and ultra-practical design, 500x500/1000mm cabinet,
light and easy to assemble
Customized arc-side locks design, the angle can be adjusted to
achieve arc, round and S-shaped splicing.
Our Services:
1. 7 Years professional led display manufacturer,
2. Shot delivery time: 5-15days.
3. Factory price.
4. OEM and ODM service
5. We can design special product for you.
6. 30% deposit for producing,70% balance to be paid before
shipment.
7. EXW, FOB, CIF C&F, FCA, DDU, colorful trade term.
FAQ:
Q1. Can I have a sample order for LED display?
A: Yes, we welcome sample order to test and check quality. Both for
module or Outdoor Digital Signage whole screen.
Q2. What about the lead time?
A: LED Modules always have stock.3 days can deliver cargo.
Q3. Do you have any MOQ limit for LED display order?
A: Low MOQ, 1 square meter or a module checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: By express,sea,air ,train
