P1.25 High Resolution SMD Small Pixel Mini LED Display Panel For
Meeting Room
Description:
1) High Reliability, Long Durability
2)Low Power Consumption, Energy Saving
3)High Brightness,Long Lifespan
4)Very Competitive Price, Good Uniformity
5) Easy and Fast Installation,Timely Delivery
Features:
1. SMD3-in-1 technology are used for indoor LED display.
2. Wide view angle: 160 in horizonal and 160 in vertical
3. Special design and advanced SMT technology improves the heat
dissipation
4. With high refresh rate controller, guarantee that no scan line
when taking photos.
5. Slim and lightweight design.
6. Easy for assembling and connecting with fast lock and the
connector added.
7. High color uniformity and clear image can bring you a vivid
audio visual effect.
Specification:
Module Specifications | 1 | Item | PH1.25 | 2 | Model Number | PH1.25-30S | 3 | Module size | 320mm*160mm | 4 | Pixel pitch | 1.25mm | 5 | Pixels Density | 640000/㎡ | 6 | Pixel configuration | 1R1G1B | 7 | Package mode | SMD1010 | 8 | Face shield | optional | 9 | Pixel resolution | 120dots(W)*135dots(H) | 10 | Max Power | 15-20W | 11 | Module thickness | 2.5mm | 12 | Weight | 0.3-0.35KG | 13 | Module connection mode | Ribbon cable connection | 14 | Drive type | Constant drive | Cabinet Data | 1 | Dimension | 640mm*480mm | 2 | Pixel per cabinet | 512dots(W)*384dots(H) | 3 | Number of modules per box | 6pcs | 4 | Material | Die-Casting aluminum | Screen Parameters | 1 | Screen Area | Customized according to cabinet size | 2 | Whole Screen Resolution |
| 3 | Scan mode | 1/32scan | 4 | Brightness of white balance | ≥400-800cd/㎡(adjustable) | 5 | Chromatic uniformity | Within 0.003Cx, Cy | 6 | Module supply voltage | 4.2V-5V(optional) | 7 | Maintenance mode | Repair and maintenance at the front | 8 | Best viewing angle | Horizontal 120° Vertical 120° | 9 | Temperature | storage:-25℃～+60℃ | 10 | working:-20℃～+50℃ | 11 | Relative humidity | 10%-75% | 12 | Average Power consumption | <150-250W/㎡ | 13 | Max.Power consumption | <400W/㎡ | 14 | Energy saving mode | optional | 15 | Operation system | Win7/Win98/me/2000/NT/XP | 16 | Control method | Synchronization | 17 | Matching receiving card | Novastar/Colorlight | 18 | Signal input | HDMI/DVI/SDI(Extensible interface) | 19 | Driving device | Constant drive IC | 20 | Refresh frequency | >3840HZ | 21 | Grey scale/colors | 15BIT | 22 | Red,Green and Blue 256 Grade/Each | 23 | MTBF | >7*24hours | 24 | Power switch | Automatic switch | 25 | The installation mode | 1,Back bracket installation
2,Stick a wall installation |
|
|
Product Picture:
Product Advantage :
1) High refresh rate , high brightness and high contrast which make
the screen without any delay and smear phenomenon under direct
sunlight.
2) Energy saving:low electric current,high-bright lamps,equipped
with PFC switching power supply that save 30% electricty.
3) The brightness can be adjustable to meet the need of changing
environment
4) Wide viewing angle: The horizontal and vertical viewing angles
are so wide that it is suitable for wide horizontal
5) Environment protection, antistatic, dust-proof, good heat
dissipation, cost-effective .
6) Error detection and monitoring:it can monitor the inner
temperature,voltage,cooling fans etc and error detection
automatically.
7) High reliability: using distributed scanning technology and
module design technology that make higher reliability and
stability.
8) Steady and reliable system:with strong anti-interference ability
and long service life that can continually work for over 24 hours,
and it’s easy to operate the system.
9) Favorable effect: using dot to dot calibration technology makes
the image clearer and the layering stronger
10) Convenient installation and maintenance of display modules
Service:
Two years quality warranty with lifelong maintenance.
Free guarantee repair (including labor and material): free for
repair service in quality warranty period and reasonable charge for
spare parts and maintaining service after the quality warranty
period. Never exempt our responsibilities on product owned defects.
Spare Parts and free CAD drawing: necessary spare parts are
provided together with products to customers.
Free Technical Training: integrative and normative technology
training is available for free to technical personnel from
customer, to ensure trainees to be skilled in regular operation of
hardware and software of the products, and be able to estimate and
solve small problems.
Site Instruction Service of installation is available.
Why choose us?
1. 10 years of experience in manufacturing LED screens of different
application
2. Implementation of the project on the screen of any complexity
3. faster delivery products from China
4. engineers' experience for 5 years
5. Technical Support (from design to debug screen display)
6. Warranty for two year and other services
FAQ:
Q1: Are you trading company or manufacturer ?
A: Scree is a professional LED display manufacturer, having been
enrolled in led display industry with professional R&D team and
skilled QC team for 11 years
Q2: What is the control system? How is it?
A: We use Novastar/Colorlight/Linsn control system. Support cluster
play and management. Support APP/ Phone/ WIFI/ Ipad/ Laptop/
PC/ Cloud control.
It’s very easy and convenient to control the screen.
Q3: What is your best service?
A: One to one sales engineer to customer responsibility system. We
will do:
1. Know your project and provide the best solution for it;
2. Track your order and let you know each step and detail of it;
3. Teach you how to install and use the screen;
4. Care the subsequent use of your screen and ensure your after -
sales service be well,
5…6…etc.
Q4. How about your delivery time?
A: Standard module we have stock ,Can send out after 7 hours aging
testing .The specific delivery time depends on the items and
the quantity of your order.
