    Full Color 3.9mm Transparent LED Video Wall Glass Window

    Ask Lasest Price
    Brand Name : ledmanner
    Model Number : P3.91-7.8
    Certification : CE
    Price : usd600-1500/㎡
    Payment Terms : T/T
    Supply Ability : 500㎡/week
    Delivery Time : 15days
    • Product Details
    • Company Profile

    Full Color 3.9mm Transparent LED Video Wall Glass Window

    Full Color Wall Panel Front Open 3.9mm Glass Window Transparent LED Display Panel


    Features:

    Reliable magnetic capacitive character design
    support various interfaces and signal sources
    advanced digital conrol technology
    support multi-transmission methods
    network control
    automatic brightness control
    super processing ability
    strong colour restoration


    Description:

    Perfect Display Effect

    High brightness and clearly display effect with easy use control system which allow you easy become enviable led display experts.

    Attractive Factory Price

    We are a professional manufacturer, has its own factories and production lines. Without middlemen and trading companies, our price is more competitive, quality is more reliable. Our price is more competitive, quality is more reliable.


    Specification:

    Pixel Pitch

    3.91mm-7.81mm

    Pixel Density

    32768dots/sqm

    Color Configuration

    1R1G1B

    LED Package

    SMD2121

    Module Size

    500mm x 250mm

    Drive Mode

    1/7 Scan

    Standard Cabinet Size

    1000mm x 500mm

    Cabinet Weight

    7KG

    Brightness

    1000 - 4200nits

    Viewing Distance

    4m-50m

    Viewing Angle

    H: 160°; V:140°

    Refresh Rate

    1920 - 3840HZ

    Frame Rate

    120frame/sec

    Grey Scale

    16.7M colors(Synchronized)

    Color Temperature

    R.G.B brightness 256 level adjustable

    Power Input

    AC110V/ 220V ±10, 50HZ

    Max Power Consumption

    500W/sqm

    Ave. Power Consumption

    200W/sqm

    Storage Temperature

    -30~+70 degree

    Working Temperature

    -20~+50 degree


    Product Picture:


    Advantage:

    Seamless connection;

    Special design for the mask to realize higher contrast (5000:1) and larger viewing angle (160°);

    Signal backup and power backup;

    Brightness and chromaticity calibration;

    Mixed use of cabinets from different batches;

    True color reproduction;

    Anti-ghost;

    High gray scale (16bit) and high refresh rate (2880Hz);

    Lower power consumption with high PFC power supply, the drive current of each LED lamp only less than 30mA;

    Customizable design.

    Supporting synchronous control /3G wireless control/Asynchronous control


    After-sales service:

    Warranty:
    1.We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.
    2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
    3.After warranty , we also can offer you the parts for replacement at our bottom price.
    4.After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it and offer you a good solution to solve the problem.
    5.We also could solve problems for you until it recovers well by remote control!


    Installation:
    1.We can assist the training and technical support for the customer in the factory, if the customer requires so.
    2.We could send our engineer to guide the installation for you. But the relevant cost should be paid by your
    esteemed company.
    3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course,
    if you need.


    FAQ:

    Q1:How to choose a led display?
    A: You should consider 3 simple questions when you choose a led screen by yourself.
    1. What's the environment- indoor or outdoor ?
    2. Is it for rental use ( need to be moved from one place to another place frequently) or for fixed installation (to be installed in a place permanently)?
    3. what is the approximate size of the led screen you would like to purchase?

    Q2:Which pixel pitch should i choose?
    A: There's a range of pixel pitch from 1.25--30mm, there is a roughly principle-usually small pixel(1.25mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen( for example huge advertisement billboard on a big building).

    Q3:Which control system should i choose?
    A:There are two kind of control systems on the market-synchronous and asynchronous control system, And for big size led screen(usually more than 20sqm) need to use synchronous control system, below 20sqm it's up to you to use syn or asyn. But asyn control system's refresh rate is much lower than sync control system and which you can use wifi, 3G, 4G etc wireless to control.

    Q4:How to order from us?
    A: You can place an order by Alibaba online or to our company directly offline, before place an order please confirm with us for every deta.
